V.E.M. GXB2-BW81364 Yellow Light 1NO+1NC 220VAC

V.E.M. GXB2-BW81364 Yellow Light 1NO+1NC 220VAC

$3.00
$3.00
Sale Sold out
Shipping calculated at checkout.

GXB2-BW81364 1NO&1NC Waterproof Illuminated Green&Red Marked Double Control Flush Head Push Button Switches

Product Name : Illuminated Double Push Button
Head Shape : Rectangle
Colors Of The Head : Green & Red
The Symbols On The Head : ━ & O
Light : With Light
Normal Color Of Light : Yellow
Lamp Insertion Way : Direct Bulb Included
Voltage:12~240V
Normal Contact Pattern : 1NO&1NC
Material : Metal
Certification : CE



① GXB2 Series

②Double Flush Button (Mark)

③Color (Upper)

④6=Direct Bulb Included

⑤Color (Bottom)

MAIN TECHNICAL DATA

  • Rated insulation voltage :600V
  • Rated thermal current:10A
  • Switch rating:AC-15 Ue:380V/250V, le=4.5A;DC-13Ue:220V/110V,le=0.6A
  • Contact resistance:≤50mA
  • Recommended torque :0.9Nm
  • Connectable area:min 1×0.5mm2,Max 2×1.5mm20r 1×2.5mm2
  • Mechanical life:Push button≥300×104 times;Selector Switch≥1004times
  • Emergency Stop Push button≥30×104 times
  • Electrical life:≥30×104 times
  • Limit voltage(lamp):0.8Ue≤U≤1.15Ue

Working Environment

  • Working environment temperature:-25~+70℃
  • Storage temperature:-40~+70℃
  • Class of pollution :3level
  • Protection grade:IP40/IP65/IP66
  • Limit height:≤2000m
  • Standard:EN 60947-1,GB14048.5

PARAMETRIC DIAGRAM
