• Standard：IEC60269-6

• Rated Voltage：DC1000V

• Rated current: 50A、63A、80A、100A、125A、160A

• Breaking capacity：50kA

• Protection object：It is used in the photovoltaic combiner box to provide safe and reliable
   protection for overload and short-circuit current faults of PV modules and PV arrays.

• Operating class：gPV

• Applicable environment：Temperature,﹣5℃～﹢40℃；Humidity, less than 90%.

ELECTRICAL TECHNICAL REFERENCE

Product model	Rated current (A)	I²t (A²s)		Power loss (w) 1.0 In	Net weight
		Melting	Clearing
SFPVNH1	50	159	1431	11.0	360g
SFPVNH1	63	467	4203	12.0
SFPVNH1	80	638	5742	15.50
SFPVNH1	100	1300	11700	16.50
SFPVNH1	125	2547	22923	17. 50
SFPVNH1	160	5198	46782	22.00

Product Type	Rated Current	Led indicator	Net weight
SFPV-NH1B	160A	NO	400g
