INVT Digital Output (Source Type) 16xDigital Output(PNP),24VDC,0.5A;RoHS
INVT Digital Output (Source Type) 16xDigital Output(PNP),24VDC,0.5A;RoHS
SKU:INVT-FL2002
Regular price
$77.87
Regular price
$97.34
Sale price
$77.87
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Cash on deliveryPay when it arrives
Delivery across Lebanon2–4 business days
5-day returnsUnused, in original packaging
Trusted since 1984Azar Group S.A.L., Zahle
The INVT FL2002 is a 16-channel PNP (source type) transistor output module from the Flex series I/O system. It switches 24 V DC loads such as relays, solenoid valves, contactors and indicator lamps from an INVT TS600 PLC or Flex coupler.
Key Features
- 16 PNP outputs: transistor source type, active high, 24 V DC.
- Protected: overheat, overcurrent, overvoltage and short-circuit protection with external power monitoring.
- Tool-free wiring: push-in terminals with colour block identification and a detachable terminal section.
- Clear diagnosis: channel-level status LEDs show the state of each point.
- Slim and modular: 12.5 mm wide; slides onto the INVT TS600 PLC or an FK EtherCAT / Modbus TCP coupler.
Technical Specifications
| Brand / Series | INVT Flex series I/O system |
| Model | FL2002 |
| Product type | Digital output, transistor source type (PNP), active high |
| Ordering code | 11016-00006 |
| Channels | 16 |
| External power | 24 V DC (-15% to +20%) |
| Output voltage | 24 V +/-10% |
| Max. output frequency | 1 kHz |
| Max. load, resistive | 0.5 A per point, 2 A per module |
| Max. load, inductive | 7.2 W per point, 12 W per module |
| Max. load, lamp | 5 W per point, 18 W per module |
| Leakage current | Less than 10 uA per point |
| Response time | 100 us (OFF-ON and ON-OFF) |
| Isolation method | Magnetic |
| Power loss | 0.77 W typical |
| Weight | 0.15 kg net |
| Dimensions (W x H x D) | 12.5 x 105 x 96 mm |
Typical Applications
- Solenoid valves, relays and contactor coils
- Indicator lamps and buzzers
- Expansion of INVT TS600 PLC systems
- Remote I/O stations on EtherCAT or Modbus TCP couplers
