DAFU Centrifugal Pump SCM2-68 2.2KW 220V/50HZ 1.5" * 1.25"

The DAFU SCM2-68 is a 2.2 kW (3 HP) two-stage centrifugal pump with two impellers working in series, so it delivers more pressure than a single-impeller pump of the same size. It is used to boost water pressure in homes, apartment buildings and farms, to fill roof tanks and to move clean water over long distances. It runs on single-phase 220 V, the standard supply in Lebanese homes and workshops.

Key Features

• Two-stage design: two impellers in series give a maximum head of 58 m.
• High flow: up to 140 litres per minute for tank filling and pressure boosting.
• Single-phase motor: runs on 220 V / 50 Hz household power or a generator.
• Self-priming from 8 m: suction head up to 8 m below the pump.
• Standard threaded ports: 1.5 inch inlet and 1.25 inch outlet.

Technical Specifications

Typical Applications

• Pressure boosting for homes and buildings
• Filling roof and ground water tanks
• Garden and farm irrigation
• Water transfer over long pipe runs
