MEAN WELL Ultra-Slim DIN Rail Power Supply - 12V DC, 2A (24W)
MEAN WELL Ultra-Slim DIN Rail Power Supply - 12V DC, 2A (24W)
SKU:MNW-HDR-30-12
Regular price
$21.32
Regular price
$26.65
Sale price
$21.32
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Cash on deliveryPay when it arrives
Delivery across Lebanon2–4 business days
5-day returnsUnused, in original packaging
Trusted since 1984Azar Group S.A.L., Zahle
The MEAN WELL HDR-30-12 is an ultra-slim 24 W DIN rail power supply with a stable 12 V DC output at up to 2 A. At only 35 mm wide it saves space in crowded electrical panels, and its universal 85-264 V AC input copes well with the voltage swings common on Lebanese grid and generator supplies. It is a reliable choice for PLCs, sensors, relays, access control, CCTV and building automation.
Key Features
- Ultra-slim profile: 35 mm wide step-shape housing that saves rail space in crowded panels.
- Universal input: 85-264 V AC or 120-370 V DC input.
- Adjustable output: front Vo ADJ trimmer sets the output from 10.8 to 13.8 V to make up for cable voltage drop.
- Full protection: short circuit, overload and over-voltage protection.
- Cool, efficient running: 88% typical efficiency and free-air convection cooling, working from -30 to +70 °C.
- Easy mounting: snaps onto TS-35/7.5 or TS-35/15 DIN rail; LED indicator for power on.
Technical Specifications
| Brand | MEAN WELL |
| Model | HDR-30-12 |
| Output voltage | 12 V DC |
| Rated current | 2 A |
| Rated power | 24 W |
| Voltage adjustment range | 10.8-13.8 V |
| Ripple and noise | 120 mVp-p max. |
| Input voltage | 85-264 V AC / 120-370 V DC |
| Frequency | 47-63 Hz |
| Efficiency | 88% typical |
| Over-voltage protection | 15-18 V |
| Protection | Short circuit / overload / over-voltage |
| Working temperature | -30 to +70 °C (see derating curve) |
| Withstand voltage | I/P-O/P 4 kV AC |
| Mounting | DIN rail TS-35/7.5 or TS-35/15 |
| Dimensions (W x H x D) | 35 x 90 x 54.5 mm |
| Weight | 0.13 kg |
| Safety approvals | UL62368-1, UL508, IEC62368-1, EN61558 |
Typical Applications
- PLCs, relays and control circuits
- Sensors, access control and intercoms
- CCTV cameras and network equipment
- Building and home automation panels
