INVT 8 Inputs And 8 Transistor Outputs, 1xUSB (Type C) 2xRS485
INVT 8 Inputs And 8 Transistor Outputs, 1xUSB (Type C) 2xRS485
SKU:INVT-PLC-TS620
Regular price
$180.22
Regular price
$225.28
Sale price
$180.22
Weight: 0.8 kg
الوزن: 0.8 kg
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Cash on deliveryPay when it arrives
Delivery across Lebanon2–4 business days
5-day returnsUnused, in original packaging
Trusted since 1984Azar Group S.A.L., Zahle
The INVT TS620 is an entry model of the TS600 intelligent PLC series with 8 digital inputs, 8 NPN transistor outputs and an Ethernet port. It controls up to 4 pulse axes and suits small machines, pumps and conveyors where a compact, fast and networkable controller is needed.
Key Features
- Compact I/O: 8 inputs and 8 outputs, all rated 200 kHz high-speed, for small machines with room to grow through Flex I/O.
- Fast processing: compiled PLC instructions with bit operations in about 0.01 us and 20K steps executed in 0.2 ms.
- Standard programming: AutoStationPro software with IEC 61131 languages LD, SFC, IL and C.
- Easy expansion: adds up to 16 INVT Flex series I/O modules with push-in terminals, plus one expansion card such as CANopen, RS232 or 2AD2DA analog.
- Data safety: program data retained at power down, a real plus where mains supply is unstable.
- Remote access: supports 4G, WiFi and RJ45 links with MQTT and API connection to the INVT IWOCloud platform.
Technical Specifications
| Brand / Series | INVT TS600 intelligent PLC |
| Model | TS620 |
| Digital inputs | 8 (all 8 are 200 kHz high-speed) |
| Digital outputs | 8 NPN transistor (all 8 are 200 kHz high-speed) |
| Ethernet ports | 1 |
| Max. axes | Up to 4 pulse axes |
| Ethernet functions | Modbus TCP/UDP, program upload/download, firmware upgrade |
| RS485 | 2 channels, Modbus RTU master/slave |
| USB | 1 x Type-C, program upload/download and firmware upgrade |
| Input power | 24 V DC (-15% to +20%), 1 A, reverse-connection and surge protection |
| Standalone power consumption | Less than 3 W |
| Backplane bus supply | 5 V / 2.5 A |
| Local expansion | Up to 16 Flex series I/O modules (no hot swapping), plus 1 expansion card (SD card, CANopen, RS232 and others) |
| Programming languages | LD, SFC, IL and C (AutoStationPro) |
| Program capacity | 200K steps; 2 MB user variables (128 KB retained at power down) |
| Instruction speed | Bit instruction 0.0127 us, word transfer 0.0014 us |
| Power-down protection | Supported (data retained in internal flash) |
| Real-time clock | Supported (optional CR2032 battery; runs about four days without battery) |
| Certification | CE |
Typical Applications
- Packaging, labelling and assembly machines
- Conveyors, pumps and process skids
- Servo and stepper positioning with pulse outputs
- Machine retrofits and panel building
